Lpg High Speed Centrifugal Spray Dryer For Food Fermented Liquid Starch Powder 2L 3L 5L 10L/H

Place of Origin China
Brand Name TIANYANG
Model Number LT-500
Minimum Order Quantity one
Delivery Time 30 Days
Payment Terms L/C, T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Fermented Liquid Spray Dryer Material SUS304, SUS316L, Ti
Max. Water Evaporation Capacity 500kg/h 1000kg/h Warranty One Year
Inlet Temperature (℃) 140-350 ℃ Out Temperature (℃) 80-90 ℃
Applications Medicine Processing, Chemicals Processing, Plastics Processing, Food Processing, Etc. Transmission Form Of Centrifugal Spray Head Mechanical Transmission
Atomization Rotated Speed (RPM) 12700 Spray Disc Diameter (mm) 180
Heating Method Electricity + Steam, Fuel Oil, Gas, Up To The User. Electric Heating Maximum Power (KW) Customized
Spray Type High Speed Centrifugal Atomizer Dimensions (L×W×H) Mm Customized
Drying Time According To Customer Requirements. Dry Powder Recovery ≥95%
Voltage 110V220V/380V/440V/Customization Core Components Bearing, Pump, Gear, Motor, Gearbox, PLC, Engine
High Light

Lpg High-speed Centrifugal Spray Dryer

,

High Speed Centrifugal Spray Dryer 10L/h

,

Fermented Liquid Centrifugal Spray Dryer

Leave a Message
Product Description

11.High Speed Fermented Liquid Centrifugal Spray Dryer

Product Description



Rotary Atomizer Type Spray Dryer Working Principle
After filtering and heating, the hot fresh air enter into the air distributor at the top of drying chamber, distributed in spiral way uniformly from up to down. At the same time, the feeding liquid is pumped to the top atomizer, then be sprayed to extremely fine mist liquid drop. Through the short time of direct contact with hot air, the moisture evaporated at once, the solid remains to be powder. The dry powder will be discharged continuously from the bottom of drying tower and cyclone collector, the exhaust air will be discharged after cleaning.


LT Series economic high performance high speed fermented liquid centrifugal spray drying equipment is a new spray drying machine researched and developed successfully by our company according to china's actual conditions after absorbing and digesting internationally advanced technology. It has features such as reasonable structure, stable performance, convenient operation, no dead corners, and no exposed bolts.



LT-1000 high speed fermented liquid centrifugal spray dryer adopts PLC automatic control. All operations are completed automatically according to the process parameters set by users. It fully meets the requirements for fermented liquid production in GMP.

Lpg High Speed Centrifugal Spray Dryer For Food Fermented Liquid Starch Powder 2L 3L 5L 10L/H 0





Technical Specifications of Fermented Liquid Spray Dryer

Model LT-1000
Max. Water Evaporation Capacity (kg/h) 1000kg/h
Material SUS304, SUS316L
Inlet Temperature (℃) 140-350℃
Out Temperature (℃) 80-90℃
Spray Type High Speed Centrifugal Atomizer
Applications Medicine processing, chemicals processing, plastics processing, food processing, etc.
Transmission Form of Centrifugal Spray Head Mechanical transmission
Atomization Rotated Speed (RPM) 12700
Spray Disc Diameter (mm) 180
Heating Method Electricity + steam, fuel oil, gas, up to the user.
Electric Heating Maximum Power (KW) Customized
Dimensions (L×W×H) mm Customized
Dry Powder Recovery ≥95%



Main Features

1. Different types of solution, suspension, emulsion and cream paste material can be dry for a one-time production.

2. The fog moment and fog droplet of spray-drying can be slightly adjusted.

3. The hot air has been reasonable allocation, and the ceiling and walls sticky situation has been eliminated.

4. It is suitable for the drying of thermo-sensitive and non thermo-sensitive material at the same time. The product particles are smaller than pressure spray dryer.

5. Simplify the production process, easy to use, good liquidity and instant of the product.



Drying Material

* Inorganic: Aluminum nitride, zirconia, potassium fluoride, bentonite, kaolin, barium sulfate, lead sulfate, sodium aluminum, chromium oxide, titanium dioxide.

* Macromolecule Polymers: Urea-formaldehyde resin, PVC.

* Dyes: Dispersol red FB, reactive dyes, etc.

* Chemical Agents: Silica dioxide, diatomite, sodium silicate, wood calcium, sodium ligninsulfonate, naphthalene series water reducer.

* Pesticide: Carbendazol chloride wettable power.

* Food and Feed Additives: casein peptide phosphate, potassium sorbate, fish serum.

* Fertilizer: Potassium humate, sodium humate.
