Powder Milk Spray Dryer Used In Pharmaceutical Industry Food Industry 50kg/H
| Place of Origin | China |
|---|---|
| Brand Name | TIANYANG |
| Model Number | LT-25 |
| Minimum Order Quantity | one |
| Delivery Time | 30 Days |
| Payment Terms | L/C, T/T |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Milk Powder Spray Dryer | Material | SUS304, SUS316L, Ti |
|---|---|---|---|
| Max. Water Evaporation Capacity | 50kg/h | Warranty | One Year |
| Inlet Temperature (℃） | 140-350℃ | Out Temperature (℃） | 80-90℃ |
| Spray Type | High Speed Centrifugal Atomizer | Applications | Dairy Products Processing, Chemicals Processing, Plastics Processing, Food Processing, Etc. |
| Transmission Form Of Centrifugal Spray Head | Compressed Air Drive | Atomization Rotated Speed (RPM) | 21500 |
| Spray Disc Diameter (mm) | 108 | Heating Method | Electricity + Steam, Fuel Oil, Gas, Up To The User. |
| Electric Heating Maximum Power (KW) | 81 | Dimensions (L×W×H) M | 3.7×3.2×5.1m |
| Dry Powder Recovery | ≥95% | Voltage | 110V220V/380V/440V/Customization |
| Core Components | Bearing, Pump, Gear, Motor, Gearbox, PLC, Engine | Use Purpose | Lab Or Pilot |
| High Light | powder spray dryer 50kg/H,spray dryer used in pharmaceutical industry,spray dryer used in food industry |
||
Product Description
7.Centrifugal Spray Dryer for Milk Powder
Product Description
LT-Series high speed centrifugal spray drying machine is suitable for various fields where the production of a powder is required.
LT-50KG high speed centrifugal spray dryer has successfully processed in the following areas: milk powder, dairy products, egg products, beverage, flavours and colourings, plant and vegetable extracts, pharmaceuticals, perfumes, blood, ceramics and superconductors biochemicals, dyestuffs, soaps and detergents, foodstuffs, adehesives, oxides, textiles and many others.
LT-50 milk spray dryer machine adopts PLC automatic control. All operations are completed automatically according to the process parameters set by users. It fully meets the requirements for milk powder processing production in GMP.
LPG series high speed centrifugal spray dryer machine
(Spray drying)Atomizing drying machine is the high efficient drying equipment, to make dry powder or granule from liquid, emulsion, suspension and pumpable pasty liquid, especially for thermosensitive material, it can keep color, original flavor and chemical feature of raw material, and the finished dry powder or granule have good quality,purity, fluidity andsolubleness.
This equipment features by high accuracy & speed & efficiency, simple production process, labor-cost saving, widely applied in the industry of chemical, food, pharmacy, biochemistry, light industry,etc.
Description :
After fresh air is filtered and heated,it enters into the air distributor which on the top of the drier.The hot air in spiral form equably enters into the drying room.When liquid raw material arepassed through the high-speed centrifugal sprayer on the top of the tower,it will be rotated and sprayed into the extreme slim mist liquid beads.Raw material can be dried to the final products instantly while it contact with the heatedair.Finished products are discharged continuously from bottom of the drying tower and cyclones segregator. Wasted air is discharged from blower.
Technical Specifications of Spray Dryer for Milk Powder
| Model | LT-50 |
| Max. Water Evaporation Capacity (kg/h) | 50kg/h |
| Material | SUS304, SUS316L, Ti |
| Inlet Temperature (℃) | 140-350℃ |
| Out Temperature (℃) | 80-90℃ |
| Spray Type | High Speed Centrifugal Atomizer |
| Applications | Dairy Products processing, chemicals processing, plastics processing, food processing, etc. |
| Transmission Form of Centrifugal Spray Head | Compressed air drive |
| Atomization Rotated Speed (RPM) | 21500 |
| Spray Disc Diameter (mm) | 108 |
| Heating Method | Electricity + steam, fuel oil, gas, up to the user. |
| Electric Heating Maximum Power (KW) | 81 |
| Dimensions (L×W×H) m | 3.7×3.2×5.1m |
| Dry Powder Recovery | ≥95% |
Features and Benefits
* Special protection function,the fan will not startand the heater will not start
* Built-in imported oil-free air compressor with noise less than 50db.
* Equipped with airinlet filter to ensure powder purity.
* Dried product has uniform particle sizemorethan95% of the dry powder is at the same particle size.
