Pressure Nozzle Spray Dryer Food Industry Coffee Extract Fish Meal Meat Essence Granules SUS316L
| Place of Origin | China |
|---|---|
| Brand Name | TIANYANG |
| Model Number | YT-Series |
| Minimum Order Quantity | one |
| Delivery Time | 30 Days |
| Payment Terms | L/C, T/T |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Pressure Spray Dryer | Material | SUS304, SUS316L |
|---|---|---|---|
| Max. Water Evaporation Capacity | 12.5-2000kg/h | Heating Method | Electricity + Steam, Fuel Oil, Gas, Up To The User. |
| Applications | Ceramics, Magnetic Materials, New Energy Materials, New Metal Materials, Chemicals, Etc. | Warranty | 1 Year |
| Inlet Temperature (℃） | 140-550℃ | Out Temperature (℃） | 80-160℃ |
| Spray Type | Pressure Nozzle | Atomization Rotated Speed (RPM) | 0-18000 |
| Transmission Form Of Centrifugal Spray Head | Mechanical Transmission | Voltage | 110V220V/380V/440V/Customization |
| Electric Heating Maximum Power (KW) | Customized | Dimensions (L×W×H) Mm | Customized |
| Core Components | Bearing, Pump, Gear, Motor, Gearbox, PLC, Engine | Use Purpose | Lab Or Pilot |
| High Light | pressure nozzle spray dryer Food,pressure nozzle spray dryer SUS316L,Pressure Spray Dryer |
||
Product Description
21.Pressure Spray Drying Granulator Mixed Flow
Product Description
1 .The drying speed is fast. The surface area of liquid raw material after being atomized will be increased greatly. 95-98% of
moisture can be evaporated at a moment. The time of drying needs about ten seconds to several tens of seconds. It is suitable for
drying heat sensitive material particularly.
2. The finished product is ball granule with uniform size. Its fluidity and solubility are good. The purity of product is high and
its quality is good.
3. The scope of application is wide. According to the characteristics of raw material, it can use hot air to dry and can also use
cool air to granulate. It has strong adaptability to raw materials.
4.Small atomizing power
5.Its operation is simple and stable and convenient and is easy to realize automatic operation.
YT series pressure spray drying granulator is a device that can complete drying and granulation at the same time and the pressure of the high-pressure pump, so that the material liquid is atomized into fine droplets and dried into powder. According to the process requirements, the pressure of the liquid pump and the size of the flow orifice can be adjusted to obtain the required spherical particles in a certain size ratio. In particular, larger diameter granular products can be obtained.
The working process of YT series pressure spray granulation drying equipment is that the material and liquid are input into the nozzle at high pressure through the high-pressure pump, spraying mist droplets, rising like a fountain, and then descending with the hot air, and most of the powder particles are discharged from the bottom of the tower. The waste gas and its tiny powder are separated by the cyclone separator, the waste gas is discharged by the exhaust fan, and the powder is collected by the pollination cylinder located at the lower end of the cyclone separator. The recovery rate is 99.5-99.8%.
The materials of the tower body, pipeline and separator of the YT series pressure spray granulation drying machine in contact with the material are all made of ICr18Ni9Ti material. There is sufficient thermal insulation layer between the inside of the tower body and the outer shell, and the filling material is ultra-fine glass wool ( Aluminum silicate thermal insulation material), the tower body is equipped with observation door, sight glass, light source and thermocouple and control instrument for temperature in and out, which are controlled and displayed by the electrical control console.
The heat source of the heating device of the equipment is electricity, which has the advantages of convenient operation, quick start, reasonable structure, compactness, clean hot air, low carbon and environmental protection. There is a controllable device in the electrical control cabinet, so that the temperature of the heater can be adjusted steplessly.
YT series pressure granulation spray dryer is especially suitable for drying granulation of alumina, zinc oxide, ferrite and ceramic materials.
Technical Parameter
| Model | YT-series Pressure Granulation Spray Dryer | ||||||||||||||
| 12.5 | 25 | 50 | 65 | 100 | 150 | 200 | 300 | 400 | 500 | 600 | 800 | 1000 | 1200 | 2000 | |
| Max. Water Evaporation Capacity (kg/h) | 12.5 | 25 | 50 | 65 | 100 | 150 | 200 | 300 | 400 | 500 | 600 | 800 | 1000 | 1200 | 2000 |
| Inlet Temperature (℃) | 140-550℃ | ||||||||||||||
| Out Temperature (℃) | 80-160℃ | ||||||||||||||
| Spray Type | Pressure Nozzle | ||||||||||||||
| Heating Sources (Option) | Oil, natural gas, coal gas, liquefied gas, marsh gas, coalmine, steam, electricity, etc. | ||||||||||||||
| Remark: Moisture steam output is related with material 's property, solid content and hot air entrance-exit temperature | |||||||||||||||
