Granule Dryer Dye Spray Dryer Ceramic Industry Automatic High Power Granulator Atomizer
| Place of Origin | China |
|---|---|
| Brand Name | TIANYANG |
| Model Number | LX Series |
| Minimum Order Quantity | one |
| Delivery Time | 30 Days |
| Payment Terms | L/C, T/T |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Centrifugal Spray Granulation Dryer | Material | SUS304, SUS316L |
|---|---|---|---|
| Max. Water Evaporation Capacity | 5-1000kg/h | Heating Method | Electricity+steam, Fuel Oil, Gas, Up To The User. Applications: Ceramics, Magnetic Materials, New Energy Materials, New Metal Materials, Inorganic Medicines, Biology, Food, Chemicals, Etc. |
| Inlet Temperature (℃） | 230-350℃ | Out Temperature (℃） | 90-150℃ |
| Spray Type | High Speed Centrifugal Atomizer | Warranty | One Year |
| Applications | Inorganic Chemicals Processing, Medicine Processing, Plastics Processing, Food Processing, Etc. | Transmission Form Of Centrifugal Spray Head | Mechanical Transmission |
| Atomization Rotated Speed (RPM) | 0-18000 | Spray Disc Diameter (mm) | 55-65 70-80 80-120 120-150 150-180 |
| Voltage | 110V220V/380V/440V/Customization | Dry Powder Recovery | ≥95% |
| Electric Heating Maximum Power (KW) | Customized | Dimensions (L×W×H) Mm | Customized |
| Core Components | Bearing, Pump, Gear, Motor, Gearbox, PLC, Engine | Use Purpose | Lab Or Pilot |
| High Light | Granule Dryer Dye,High Power Granulator Atomizer,spray dryer ceramic industry |
||
Product Description
13Automatic Energy-saving Centrifugal Spray Granulation Dryer
Product Description
Application:
Centrifugal spray dryer is the most widely used process in liquid shaping technology. Can be used for:
Chemical industry: sodium fluoride (potassium), basic dyes and pigments, dye intermediates, compound fertilizers, formaldehyde silicic acid, catalysts, sulfuric acid, amino acids, white carbon black, etc.
Plastic resin: AB, ABS emulsion, urinary formaldehyde resin, phenolic resin, dense rubber (urea) formaldehyde resin, polyethylene, polyvinyl chloride, etc.
Food industry: fat-rich milk powder, gluten, cocoa milk powder, milk substitutes, blood hunting powder, egg white (yellow), etc.
Food and plants: oats, chicken juice, coffee, instant tea, flavored meat, protein, soybean, peanut protein, hydrolysate, etc.
Sugars: corn syrup, corn starch, glucose, pectin, maltose, potassium sorbate, etc.
Ceramics: alumina, ceramic tile materials, magnesium oxide, talcum powder, etc.
Technical Parameter:
LX-Series fully automatic energy-saving centrifugal spray granulation dryer (hot air drying) is mainly for the slurry with high solid content to be sprayed and granulated by a high-speed centrifugal atomizer. Filling the film, the residual moisture content and loose specific gravity are stable, and it is suitable for isostatic pressing and molding products. The service life of the mold is relatively longer than that of manual and mechanical granulation. The pressed product has better consistency and higher finish.
Main Features
* Fast drying speed and high efficiency;
* It can handle high concentration and high viscosity liquid;
* Products with less fine powder content and good dispersibility, fluidity and solubility can be obtained;
* The product has good sphericity and excellent particle size distribution, and the particle size of the product can be adjusted arbitrarily;
* The production process is simplified, automatic control, convenient operation, suitable for continuous production control.
Scope of Application
LX-series automatic energy-saving centrifugal spray granulation drying equipment has been used in electronic ceramics, precision ceramics, ceramics, magnetic materials, new energy materials, new metal materials, inorganic medicines, biology, food, chemicals, fine chemicals and other industries.
Technical Parameter
| Model | LX Centrifugal Spray Granulation Drying Machine | |||||||||||||||||
| Max. Water Evaporation Capacity (kg/h) | 5 | 10 | 15 | 20 | 25 | 30 | 50 | 100 | 120 | 150 | 200 | 300 | 400 | 500 | 600 | 800 | 1000 | |
| Inlet Temperature (℃) | 230-350℃ | |||||||||||||||||
| Out Temperature (℃) | 90-150℃ | |||||||||||||||||
| Spray Type | High Speed Centrifugal Atomizer | |||||||||||||||||
| Atomization Rotated Speed (RPM) | 0-18000 | |||||||||||||||||
| Spray Disc Diameter (mm) | 55-65 | 70-80 | 80-120 | 120-150 | 150-180 | |||||||||||||
| Heating Sources (Option) | Oil, natural gas, coal gas, liquefied gas, marsh gas, coalmine, steam, electricity, etc. | |||||||||||||||||
Remarks: Water evaporation capacity depends material property, solid content, inlet & outlet temperature.
