Instant Coffee Milk Powder Spray Dryer Atomizer Fine Stevia Algae Tea Fruit Extraction 200kgh
| Place of Origin | China |
|---|---|
| Brand Name | TIANYANG |
| Model Number | LT-Series |
| Minimum Order Quantity | one |
| Delivery Time | 30 Days |
| Payment Terms | L/C, T/T |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Spray Drying Equipment | Spray Type | High Speed Centrifugal Atomizer |
|---|---|---|---|
| Warranty | 1 Year | Applications | Medicine Processing, Biological, Food, Medicine, Etc. |
| Drying Time | According To Customer Requirements. | Max. Water Evaporation Capacity | 5-3000kg/h |
| Voltage | 110V220V/380V/440V/Customization | Power | 3-75kw |
| Dimension(L*W*H) | Variable | Core Components | Bearing, Pump, Gear, Motor, Gearbox, PLC, Engine |
| Material | SUS304, SUS304L, SUS316, SUS316L, Ti, Other, SS304 And 316L | Use Purpose | Lab Or Pilot |
| Atomizer | Centrifugal Atomizer | Heating Sources (Option) | Oil, Natural Gas, Coal Gas, Liquefied Gas, Marsh Gas, Coalmine, Steam, Electricity, Etc. |
| Inlet Temperature (℃） | 140-350 ℃ | Out Temperature (℃） | 80-90 ℃ |
| Rotating Speed | 11800-25000rpm | Spray Disc Diameter (mm) | 60 120 150 180 210 |
| High Light | spray dryer atomizer,Instant Coffee Spray Dryer Milk Powder Spray Drying Machine,Milk Powder Spray Dryer 200kgh |
||
Product Description
1.LT Series High Speed Centrifugal Spray Dryer
Product Description
Main Features
1.The drying speed is fast, and the surface area of the material liquid is greatly increased after atomization. In the hot air
flow, 95% - 98% of water can be evaporated instantly, and the drying time is only a few seconds. It is especially suitable for the drying of heat sensitive materials.
2.The product has good uniformity, fluidity and solubility, high purity and good quality.
3.The production process is simple and easy to operate and control. The liquid with moisture content more than 90(40% - 60% for special materials) can be dried into powder products at one time. After drying, there is no need to crush and screen, which reduces the production process and improves the product purity. The particle size, bulk density and moisture of the product can be adjusted by changing the operating conditions within a certain range, which is very convenient for control and management.
LT series high speed centrifugal spray dryer is a new type of high-efficiency drying process equipment, which can make solutions, emulsions, suspensions, and paste liquid materials through spray drying into dry powder, fine and medium particles.
LT series high speed centrifugal spray drying machine has fast drying speed, high efficiency, few processes and labor saving. The product quality is stable, and the finished product has good fluidity and good solubility after drying. It has the advantages of high purity and good environmental sanitation. It is beneficial to increase the output and obtain good process technology and economic benefits.
LT series high speed centrifugal spray drying equipment is especially suitable for heat-sensitive materials, drying can keep the color, aroma and taste of the dried materials unchanged. It has a bright future in chemical, fine chemical, light industry, ceramic materials, electronics, food, biology, Chinese and Western medicine, biochemistry, environmental protection and other industries.
Main Features
* Drying speed is very fast;
* Product quality is good;
* Product has good dispersibility, fluidity and solubility;
* Production process is simplified, easy to operate and control;
* The air drying chamber wall of the drying chamber is used to eliminate or reduce the stick wall phenomenon;
* Drying chamber wall and roof top adopt air cooling system to prevent material from melting hot wall;
* The powder collection system uses dehumidification air cooling technology to prevent moisture absorption and agglomeration of the product and facilitate product packaging;
* Meets the requirements of GMP national standards, and the air cleanliness of contact with materials reaches.
Types of Dry Products (Parts)
| * Polymers and resins | * Tannic acid |
| * Dyes, colors, pigments | * Non-staple food, blood and fish products in slaughterhouses |
| * Ceramic materials, glass ceramic sand | * Detergents and surface stains |
| * Rust remover fungicides insecticides | * Ingredients |
| * Carbohydrates and similar products | * Organic chemicals |
| * Dairy and eggs | * Inorganic chemicals |
| * Food and plant extracts | * Cellulose |
| * Chinese and Western medicines, biological fermentation products | * By-products and other sundries, etc |
Technical Parameter
| Model | LT High Speed Centrifugal Spray Dryer | |||||||||||||
| Max. Water Evaporation Capacity (kg/h) | 5 | 25 | 50 | 100 | 150 | 200 | 300 | 400 | 500 | 600 | 1000 | 1200 | 2000 | 3000 |
| Inlet Temperature (℃) | 140-350 ℃ | |||||||||||||
| Out Temperature (℃) | 80-90 ℃ | |||||||||||||
| Spray Type | High Speed Centrifugal Atomizer | |||||||||||||
| Atomization Rotated Speed (RPM) | 25000 | 18000-22000 | 15000-22000 | 12700 | 11800 | |||||||||
| Spray Disc Diameter (mm) | 60 | 120 | 150 | 180 | 210 | |||||||||
| Heating Sources (Option) | Oil, natural gas, coal gas, liquefied gas, marsh gas, coalmine, steam, electricity, etc. | |||||||||||||
Remarks: Water evaporation capacity depends material property, solidcontent, warmairinlet & outlet temperature.
